2Mp AI WIFI Baby camera, two-way speech intercom, VicoHome APP, 7Days 1G free cloud, 360° Full view, Cloud storage.

2023-3-30 14:27:55, Visits：

Product Model:	AI-PTX02-JW2H1
FOB Price:	US$14.56-US$15.56
Min. Order:	1pc

Product Brand:	IdeaCamera
OEM/ODM:	Support
Warranty:	2 Years
Country of Origin:	China
Certificate:	CE,FCC,ROHS
PDF:

Inquire Now >

Model: AI-PTX02-JW2H1

Product features：

White plastic housing.

10pcs IR night vision LEDs.

HD 4mm wide angle Lens.

Power in: 5V 1.5A

The installation is simple and easy to use.

Clear and smooth images, intelligent transmission to play the limits of the network.

Online firmware upgrade, synchronous update function.

Support for two-way voice talk, echo elimination, noise reduction.

Support Android, IOS smart terminal remote real-time monitoring.

200W(1920X1080), high-definition image quality.

Infrared light (night vision distance of 7 meters), day and night 24-hour monitoring, IR-CUT switching, daytime color, night vision clearer.

Support 2.4G Wi-Fi (IEEE802.11b/g/n).

Smart push, filter out useless information.

Smart storage algorithm, small space to accommodate more content, support Micro SD card, cloud storage.

Support 7days 1G free cloud storage.

Support to scan the QR Code to connect Camera.

Support for humanoid detection, electronic fences, intelligent push, pet capture.

The appearance is small and beautiful, the color is diverse.

Minimum order quantity: 200pcs.

Items		parameters
Processor	SOC	ARM
Image sensor	Sensor	1/3" color CMOS sensor, 2.0 megapixel.
	Lens	M12, f: 3.6mm, F2.0, 2mp
	Angle of View	H (horizontal) 85 degrees; V (vertical) 48 degrees; D (verse) 100 degrees
	Minimum Illumination	0.01Lux
	IR Range	Up to 10m IR range
Audio	Input / Output	Two-way voice intercom available (built-in Microphone and speaker).
Video	Video Compression	H.265, H.264
	Lighting frequency	50Hz, 60Hz
	Image frame rate	15fps
	Maximum image	1920*1080P
	Night vision	IRCUT dual-light automatically switches, 6 infrared lamps (850nm wavelength), irradiated distance: 7 meters
Network	Protocols	TCP/IP, UDP/IP, DHCP, RTMP, MUTP
	Wireless Network	2.4G Wi-Fi (IEEE802.11b/g/n), built-in antenna.
	IP Address Supported	Dynamic IP address supported.
Alarm	Alarm linkage	Support video recording, sound alarm.
Alarm	Alarm notification	Alarm push by mobile APP.
Smart	Smart feature	Smart push, pet capture, humanoid detection, motion tracking
Pan-Tilt	Rotation	H (horizontal) 0° ~ 355°; V (vertical) -20° ~ 90°
Interface	Power Supply	1 Micro USB interface, DC 5V/1A
	SD card	1 Micro SD card slot
	Keys	1 function key
Others	Lens adjustable	Cannot
	LED indication	Monochrome white light (power/network signal/function indicator).
	Storage method	Micro SD card（maximum support 128GB）local storage, cloud storage
	Installation method	Ceiling or wall hanging
Environment	Dustproof and waterproof	no
	Work environment	-10° ~ 45°C /10% ~ 80% (no condensation)
	Storage environment	-20°C ~ 60° /0% ~ 90% (no condensation)
Appearance color	Appearance color	Available in black, white, grey, yellow, purple, pink
Specifications	Size(LxWxH)	72mm72mm115.5mm
Specifications	Weight (without package)	Around 180g
Certification	Certificate	CE, FCC, RoHS, WEEE
